ODME SEILS SERIES - KOREA

- 1 Controller (DC24V )
- 1 Oil Content meter with 4 silent blocks 220V, 60Hz, 1Ph, IP44
- 1 PPM Measurer on its tape
- 1 Hydraulic panel including 4 sets of 2-way pneumatic valve with 1 filter
- 1 Pressure switch
- 1 Motor/pump assembly
- 1 Sample probe (SUS316L) with 1 set of stop valve 3/4” BSP(Tapered)
- 1 Flowmeter type pitot tube(AISI 316L) and ΔP transmitter (SUS316)
with 1 set of stop valve 1/4” BSP (Tapered)
- 1 Motor starter IP44 with cable glands, door with door stopper and earthing cable
(Main supplied voltage : 440V, 60Hz, 3Ph
Control circuit voltage : 220V, 60Hz, 1 Ph )
- 1 Set of necessary valves required for system including :
1 Stop valve 3/4" BSP Tapered with bite type connectors
2 Stop valve 1/2” BSP (Tapered), SUS316
2 Stop valve 1/4” BSP(Tapered), Brass
2 Globe check valve 5K-15A, Bronze
1 Non return valve 1/2” BSP (Tapered), SUS316
1 3-way test valve, SUS316
1 Safety Relief Valve 1/2”, SUS316
1 Pressure Regulator
1 Air Filter Regulator
- 1 Copy of DNV Type approval certificate on the ODME S-3000VER.2
- 3 Copies of Technical manual without the class approval
- 1 Set of basic spare parts for the ODME.
