Type | CleanTrack 1000 B |
Application | Oil Discharge Monitoring and Control System for Oil Tankers in accordance with MEPC.108(49) as amended by Resolution MEPC.240(65), approved for Crude oils and Petroleum products as well as for 10 types of Bio-fuel blends in accordance with MEPC.1/Circ.761 as revised. 0 - 1000 ppm |
Range | |
Accuracy Sample Flow rate |
According to MEPC.108(49) 240 liters/hour to 900 liters/hour depending on sample pump model. |
Clean water connection (optional): | |
Flow rate | Intermittently 200 to 600 liters/hour depending on sample pump model and water pressure. Clean water is only used at Discharge Start and Stop. Approximately 6-20 liters per Start/Stop (when applicable). max. 5 bar |
Pressure |
min. 0.5 bar higher than the pressure in the overboard line at the sample
outlet connected point.
